Patriot Docks Premium Floating Dock With Gray Aluminum Deck

Patriot Docks Premium Low-Profile Floating Dock w/ Gray Aluminum Decking

Upgrade your waterfront lifestyle with Premium Aluminum Floating Docks by Patriot Docks. Measuring 96” x 48” x 4-1/2”, and only weighing 50 lbs, these top-tier aluminum floating dock kits are engineered for durability and ease of maintenance, with sleek gray aluminum decking that offers modern aesthetics and long-lasting performance. Able to adapt to variable water conditions, they provide a stable and stylish platform for all your water activities.

The Premium Floating Dock is supported by (2) 48” x 24” x 12” foam filled rectangular floats EVERY 8ft of dock frame, with a total buoyancy rating of 400 lbs. per float. With a UV protected, impact resistant outer shell, these floats will battle the most challenging water conditions. Patriot Docks foam floats provide unmatched performance buoyancy and are U.S. Coast Guard Approved.

Stability is crucial to the performance of any floating dock system. The Patriot Docks Premium Floating Dock includes (4) Side Stability Floats for every 8 ft section of dock frame. The impact resistant HDPE outer shell with EPS foam fill will stand the test of time and abuse in any marine environment. The Side Stability Float measures 43” x 13” x 7” and weighs only 14 lbs. With 150 lbs. of tank tested buoyancy rating, the Side Stability Float will not only increase your docks usable surface area but add critical load support for your floating dock structure.

Features:

• Corrosion-resistant foam helps maintain stability on the water
• Stability floats add critical load support and usable surface area
• To eliminate stress the unique hinge system allows the dock to move with changing water conditions
• The Low-Pro tubular aluminum frame allows the modular floating dock to sit closer to the water than any other dock in the market
• Excellent in deep or fluctuating water levels and extremely soft lake bottoms

24' Floating Dock Kit Includes:

• (3) 4' x 8' Low profile floating dock frame + hardware
• (4) 48" x 24" x 12" Foam filled rectangular floats + plug
• (4) J-bolt float mounting hardware set
• (8) 43" x 13" x 7" Side stability floats + hardware
• (1) Floating hinge kit + hardware
• (4) 3" Steel piling sleeves + hardware (accepts up to 2" O.D. pipe)
• (6) 4' x 4' Gray Aluminum deck panels
• Assembly instructions

32' Floating Dock Kit Includes:

• (4) 4' x 8' Low profile floating dock frame + hardware
• (6) 48" x 24" x 12" Foam filled rectangular floats + plug
• (6) J-bolt float mounting hardware set
• (12) 43" x 13" x 7" Side stability floats + hardware
• (2) Floating hinge kit + hardware
• (4) 3" Steel piling sleeves + hardware (accepts up to 2" O.D. pipe)
• (8) 4' x 4' Gray Aluminum deck panels
• Assembly instructions

40' Floating Dock Kit Includes:

• (5) 4' x 8' Low profile floating dock frame + hardware
• (8) 48" x 24" x 12" Foam filled rectangular floats + plug
• (8) J-bolt float mounting hardware set
• (16) 43" x 13" x 7" Side stability floats + hardware
• (2) Floating hinge kit + hardware
• (4) 3" Steel piling sleeves + hardware (accepts up to 2" O.D. pipe)
• (10) 4' x 4' Gray Aluminum deck panels
• Assembly instructions

Vertical piling pipe is NOT included. Customer is responsible for determining acceptable anchoring method.
